PCI-7396 - 96-CH High-Driving DIO Card

PCI-7396 - 96-CH High-Driving DIO Card
Main features



  • Output port status read back
  • Programmable port configuration as input or output
  • High driving capacity up to 48 mA (sink) and 15 mA (source)
  • 96 CH digital TTL inputs/outputs
  • Supports 32-bit 5 V PCI bus
  • On-board 8254 timer/counter chip
  • Change-Of-State (COS) interrupt
  • Multiple programmable interrupt sources





The PCI-7396 is 96-bit parallel digital input/output (DIO) cards designed for industrial applications. The PCI-7396 emulates four 8255 Programmable Peripheral Interface (PPI) chips. Each PPI offers three 8-bit DIO ports which can be accessed simultaneously. The total 12/6 ports can be configured as input or output independently.The PCI-7396 devices feature external trigger to latch the digital input data, and also provides “Change-of-State” (COS) interrupt, which means when any of the digital inputs changes its state, an interrupt will be generated. Users can power up the PCI-7396 digital I/O lines in a user-defined state – either high or low, by simply setting the pull-high/pulllow resistors with a jumper.

Prix HT : 999999,00
