DNx-AI-207 - 16-channel, 18-bit, 1 kS/s per channel, analog input, data acquisition board

DNx-AI-207 - 16-channel, 18-bit, 1 kS/s per channel, analog input, data acquisition board
Main features
  • 16 differential channels
  • Additional dedicated CJC channel
  • Maximum sampling rate of 1kHz per channel
  • 18-bit resolution
  • ±10V input range
  • Gains – 1,2,4,8,10,20,40,80,100,200,400,800
  • Overvoltage protection (-40V to +55V)
  • Direct Inputs for thermocouples (with DNA-STP-AI-U panel)
  • Embedded averaging engine

UEI card DNx-AI-207 18-bit 16Ks/s

Technical specifications

The UEI manufacturer’s card, DNX-AI-207 is a multiplexed differential analog acquisition card with 16 channels (including a dedicated thermocouple channel) with a maximum sampling frequency of 1Ks/s per channel for all the channels, with a resolution of 18 bits and an input range of +/- 10 Volt. A programmable gain of 1,2,4,8,10,20,40,80,100,200,400 and 800. Additionally, the DNx-AI-207 provides a dedicated CJC channel, which can be used for temperature reading from the built-in CJC sensor on DNA-STP-AI-U terminal blocks or DNA-STP-AI-207TC terminal blocks. . The card has surge protection (-40V to + 55V).

Software and drivers

The UEIDAQ Framework library uses the same API to access all devices of the DNx distributed cards. Using the UEIDAQ Framework library significantly reduces the amount of code required to perform data acquisition and control applications. UEI supports all 32/64 bit versions of Windows up to the most recent version of Windows 10. The UEIDAQ Framework provides a set of C ++ classes to easily interface your C ++ programs with acquisition devices UEI data. The UEIDAQ Framework also comes with an ANSI-C API. Instantly download Windows software and drivers for PowerDNA / DNR hardware from the UEI. Includes UEIDAQ Framework library, which supports the following software: VisualBASIC 6, VB.NET, LabVIEW, MATLAB, LabWindows / CVI, OPC server, Excel, .NET, C #, C / C ++, Borland Delphi, Borland C ++ Builder.

Depending on the reception station, the card references will be:

– DNA-AI-207 for Cubes
– DNR-AI-207 for Racks
– DNF-AI-207 for the FLATRACK

Card usable with the UEILogger.
