8540/8650 Mod

Directly measure the instantaneous peak power level of a pulse modulated signal. Use the “sample delay” function to set the desired measurement point on the waveform. And an external scope can be used to view the profile and see the exact measurement point on the pulse.

  • 80350A Series, -20 dBm to +47 dBm, 45 MHz to 40 GHz

This sensor series works with the 8540B, 8540C, 8650A, 8650B and 58542 VXI series power meter.

Datasheet for all power sensors listed above can be found in all models power meter and scalar network analyzer datasheet.
